Osmium

Osmium Navigation

Other Elements

By Name

By Symbol

By Number

Quantity

Osmium Quick Reference

Click button to see citations

Notes

Symbol

Os

Atomic Number

76

Atomic Weight

Rounded

190.23

for regular calculations

Standard

190.23 ± 0.03

for precise calculations

Oxidation States

 8

less common with disagreement

 7

less common

 6

less common with disagreement

 5

less common

 4

more common

 3

less common

 2

less common

 1

less common

 0

less common

-2

less common

Pauling Electronegativity

2.2

Electron Configuration

Orbital Occupancy

[Xe] 4f14 5d6 6s2

[Xe] represents the closed-shell electron configuration of xenon

Orbital Filling Order

[Xe] 6s2 4f14 5d6

[Xe] represents the closed-shell electron configuration of xenon

Term Symbol

5D4

see expanded configuration ...

Ionization Energies

I (1)

8.43823 eV

Electron Affinity

1.07780 ± 0.00012 eV

   8693 ± 1 cm-1

Density

liquid, 3306.15 K

20.100 g/ml

solid

25 °C

22.590 g/cm3

20 °C

22.587 ± 0.009 g/cm3

densest metal at 20 °C

Molar Volume

solid, 298 K, 1 atm

8.42 cm3/mol

Melting Point

1 atm

3400 ± 50 K

Boiling Point

1 atm

5576 ± 30 K

reference stated that the uncertainty may be larger than indicated

Thermal Conductivity

solid

400 K, polycrystalline

86.9 W/(m K)

300 K, polycrystalline

87.6 W/(m K)

extrapolated or interpolated

298.2 K, polycrystalline

87.6 W/(m K)

extrapolated or interpolated

273.2 K, polycrystalline

88.0 W/(m K)

extrapolated or interpolated

200 K, polycrystalline

90.8 W/(m K)

extrapolated or interpolated

see all 43 conductivities ...

Pyykkö Covalent Radius

single bond

129 pm

double bond

116 pm

triple bond

109 pm

Atomic Radius

135 pm

Enthalpy of Fusion

1 atm

29.3 kJ/mol

Enthalpy of Vaporization

1 atm

627.6 kJ/mol

Quantity

Osmium Atomic Structure

Notes

Ionization Energies

I (1)

8.43823 eV

Electron Affinity

1.07780 ± 0.00012 eV

   8693 ± 1 cm-1

Electron Binding Energies

K    (1s)

73871 eV

LI   (2s)

12968 eV

LII  (2p1/2)

12385 eV

LIII (2p3/2)

10871 eV

see all 19 energies ...

Electron Configuration

Orbital Occupancy

[Xe] 4f14 5d6 6s2

[Xe] represents the closed-shell electron configuration of xenon

Orbital Filling Order

[Xe] 6s2 4f14 5d6

[Xe] represents the closed-shell electron configuration of xenon

Term Symbol

5D4

see expanded configuration ...

Clementi-Raimondi Effective Nuclear Charge

1s

Orbital Exponent

74.5299

ζ

Principle Quantum Number

1

n

Effective Nuclear Charge

74.5299

Zeff = ζ × n

2s

Orbital Exponent

28.0749

ζ

Principle Quantum Number

2

n

Effective Nuclear Charge

56.1498

Zeff = ζ × n

see all 14 effective nuclear charges ...

Screening Percentage

86.6%

Fluorescence Yields

ωK

0.957

ωL1

0.15

ωL2

0.318

ωL3

0.282

Coster-Kronig Yields

F12

0.07

F13

0.482

F23

0.13

Quantity

Osmium Physical Properties

Notes

Density

liquid, 3306.15 K

20.100 g/ml

solid

25 °C

22.590 g/cm3

20 °C

22.587 ± 0.009 g/cm3

densest metal at 20 °C

Molar Mass

Rounded

190.23 g/mol

for regular calculations

Standard

190.23 ± 0.03 g/mol

for precise calculations

Molar Volume

solid, 298 K, 1 atm

8.42 cm3/mol

Physical Form

blue-white metal

Linear Thermal Expansion Coefficient

25 °C

5.1×10-6 K-1

Speed of Sound

solid, 293 K

4940 m/s

calculated value

Young's Modulus

558.6 GPa

Poisson's Ratio

0.250

Electrical Resistivity

solid, 295 K

9.1×10-8 Ohm m

Contact Potential

4.55 eV

Superconducting Transition Temperature

ambient pressure

0.655 K

0 Pa

0.655 K

Superconducting Critical Magnetic Field at Absolute Zero

65×10-4 T

Mineralogical Hardness

7.0

Isothermal Bulk Modulus

300 K

418 GPa

estimated

Isothermal Compressibility

300 K

0.0024 GPa-1

estimated

Gram Atomic Volume

9 cm3

Quantity

Osmium Atomic Interaction

Notes

Oxidation States

 8

less common with disagreement

 7

less common

 6

less common with disagreement

 5

less common

 4

more common

 3

less common

 2

less common

 1

less common

 0

less common

-2

less common

Pauling Electronegativity

2.2

Allred-Rochow Electronegativity

1.52

Configuration Energy

electron volt units

9.78 eV

Pauling units

1.65

Nagle Electronegativity

1.39

Pearson Absolute Electronegativity

4.9 eV

Chemical Hardness

3.8 eV

Cohesive Energy

per mole

788 kJ/mol

per atom

  8.17 eV/atom

Quantity

Osmium Thermodynamics

Notes

Melting Point

1 atm

3400 ± 50 K

Boiling Point

1 atm

5576 ± 30 K

reference stated that the uncertainty may be larger than indicated

Thermal Conductivity

solid

400 K, polycrystalline

86.9 W/(m K)

300 K, polycrystalline

87.6 W/(m K)

extrapolated or interpolated

298.2 K, polycrystalline

87.6 W/(m K)

extrapolated or interpolated

273.2 K, polycrystalline

88.0 W/(m K)

extrapolated or interpolated

200 K, polycrystalline

90.8 W/(m K)

extrapolated or interpolated

see all 43 conductivities ...

Critical Point

12700 K

Vapor Pressure

5576 K

1 atm

5571 K

1 bar

4810 K

1×10-1 bar

4239 K

1×10-2 bar

3400 K

7.753×10-5 bar

melting point

see all 19 pressures ...

Enthalpy of Fusion

1 atm

29.3 kJ/mol

Enthalpy of Vaporization

1 atm

627.6 kJ/mol

Isobaric Molar Heat Capacity

298.15 K, 1 bar

24.7 J/(mol K)

Isobaric Specific Heat Capacity

298.15 K, 1 bar

0.130 J/(g K)

Electronic Heat Capacity Coefficient

2.05 mJ/(mol K2)

Debye Temperature

Low Temperature Limit ( 0 K )

467 K

Room Temperature ( 298 K )

400 K

Quantity

Osmium Identification

Notes

CAS Number

7440-04-2

Quantity

Osmium Atomic Size

Notes

Atomic Radius

135 pm

Orbital Radius

126.6 pm

Pyykkö Covalent Radius

single bond

129 pm

double bond

116 pm

triple bond

109 pm

Cordero Covalent Radius

144 pm

Shannon-Prewitt Crystal Radius

ion charge: +4, coordination number: 6

77.0 pm

ion charge: +5, coordination number: 6

71.5 pm

ion charge: +6

coordination number: 5

63 pm

coordination number: 6

68.5 pm

ion charge: +7, coordination number: 6

66.5 pm

ion charge: +8, coordination number: 4

53 pm

Shannon-Prewitt Effective Ionic Radius

ion charge: +4, coordination number: 6

63.0 pm

ion charge: +5, coordination number: 6

57.5 pm

ion charge: +6

coordination number: 5

49 pm

coordination number: 6

54.5 pm

ion charge: +7, coordination number: 6

52.5 pm

ion charge: +8, coordination number: 4

39 pm

Batsanov Crystallographic Van Der Waals Radius

2.0×102 pm

Batsanov Equilibrium Van Der Waals Radius

233 pm

Slater Atomic-Ionic Radius

130 pm

Quantity

Osmium Crystal Structure

Notes

Nearest Neighbor Distance

300 K, 1 atm

268 pm

Atomic Concentration

300 K, 1 atm

7.14×1022 cm-3

Quantity

Osmium History

Notes

Discovery

date of discovery

1804

discoverer

Smithson Tennant

birth

November 30, 1761

death

February 22, 1815

location of discovery

London, England

Origin of Element Name

origin

osme

origin description

property—Greek for odor or smell

Origin of Element Symbol

symbol: Os

origin

osmium

origin description

element name

Quantity

Osmium Abundances

Notes

Earth's Crust

1.5×10-3 ppm

Earth's Mantle

3.4 ppb

primitive mantle

Earth's Core

2.8 ppm

Bulk Earth

0.9 ppm

U.S. Coal

<0.001 ppm

estimated from USGS and literature data

Solar System

0.675

number of atoms for every 106 atoms of silicon

Sun

1.45 ± 0.10

base 10 log of the number of atoms for every 1012 atoms of hydrogen

Meteorites

1.38 ± 0.02

base 10 log of the number of atoms for every 1012 atoms of hydrogen

Quantity

Osmium Nomenclature

Notes

Element Names in Other Languages

French

osmium

German

Osmium

Italian

osmio

Spanish

osmio

Portuguese

osmio

Anions or Anionic Substituent Groups

osmide

Cations or Cationic Substituent Groups

osmium

Ligands

osmido

Heteroatomic Anion

osmate

'a' Term—Substitutive Nomenclature

osma

'y' Term—Chains and Rings Nomenclature

osmy

References    (Click the button next to a value above to see complete citation information for that entry)

A., J. W. "Osmium, the Densest Metal Known." Platinum Metals Review, volume 39, number 4, 1995, p. 164.

Anders, Edward, and Nicolas Grevesse. "Abundances of the Elements: Meteoritic and Solar." Geochimica et Cosmochimica Acta, volume 53, number 1, 1989, pp. 197–214. doi:10.1016/0016-7037(89)90286-X

Andersen, T., H. K. Haugen, and H. Hotop. "Binding Energies in Atomic Negative Ions: III." Journal of Physical and Chemical Reference Data, volume 28, number 6, 1999, pp. 1511–1533.

Arblaster, J. W. "Vapour Pressure Equations for the Platinum Group Elements." Platinum Metals Review, volume 51, number 3, 2007, pp. 130–135. doi:10.1595/147106707X213830

Arblaster, J. W. "What is the True Melting Point of Osmium?" Platinum Metals Review, volume 49, number 4, 2005, pp. 166–168. doi:10.1595/147106705X70264

Arblaster, J. W. "Thermodynamic Properties of the Platinum Metals on ITS-90." Platinum Metals Review, volume 40, number 2, 1996, pp. 62–63.

Batsanov, S. S. "Van der Waals Radii of Elements." Inorganic Materials, volume 37, number 9, 2001, pp. 871–885. See abstract

Campbell, J. L. "Fluorescence Yields and Coster–Kronig Probabilities for the Atomic L Subshells. Part II: The L1 Subshell Revisited." Atomic Data and Nuclear Data Tables, volume 95, number 1, 2009, pp. 115–124. doi:10.1016/j.adt.2008.08.002

Campbell, J. L. "Fluorescence Yields and Coster–Kronig Probabilities for the Atomic L Subshells." Atomic Data and Nuclear Data Tables, volume 85, number 2, 2003, pp. 291–315. doi:10.1016/S0092-640X(03)00059-7

Cardarelli, François. Materials Handbook: A Concise Desktop Reference, 2nd edition. London: Springer–Verlag, 2008.

Clementi, E., D. L. Raimondi, and W. P. Reinhardt. "Atomic Screening Constants from SCF Functions. II. Atoms with 37 to 86 Electrons." Journal of Chemical Physics, volume 47, number 4, 1967, pp. 1300–1307. doi:10.1063/1.1712084

Cohen, E. Richard, David R. Lide, and George L. Trigg, editors. AlP Physics Desk Reference, 3rd edition. New York: Springer-Verlag New York, Inc., 2003.

Connelly, Neil G., Ture Damhus, Richard M. Hartshorn, and Alan T. Hutton. Nomenclature of Inorganic Chemistry: IUPAC Recommendations 2005. Cambridge: RSC Publishing, 2005.

Cordero, Beatriz, Verónica Gómez, Ana E. Platero-Prats, Marc Revés, Jorge Echeverría, Eduard Cremades, Flavia Barragán, and Santiago Alvarez. "Covalent Radii Revisited." Dalton Transactions, number 21, 2008, pp 2832–2838. doi:10.1039/b801115j

de Podesta, Michael. Understanding the Properties of Matter, 2nd edition. London: Taylor & Francis, 2002.

Debessai, M., J. J. Hamlin, and J. S. Schilling. "Comparison of the Pressure Dependences of Tc in the Trivalent d-Electron Superconductors Sc, Y, La, and Lu up to Megabar Pressures." Physical Review B, volume 78, number 6, 2008, pp. 064519–1 to 064519–10. doi:10.1103/PhysRevB.78.064519

Dronskowski, Richard. Computational Chemistry of Solid State Materials. Weinheim, Germany: WILEY-VCH Verlag GmbH & Co. KGaA, 2005.

Emsley, John. Nature's Building Blocks: An A-Z Guide to the Elements. Oxford: Oxford University Press, 2003.

Emsley, John. The Elements, 3rd edition. Oxford: Oxford University Press, 1998.

Firestone, Richard B. Table of Isotopes, 8th edition, volume 2. Edited by Virginia S. Shirley, with assistant editors Coral M. Baglin, S. Y. Frank Chu, and Jean Zipkin. New York: John Wiley & Sons, Inc., 1996.

Greenwood, N. N., and A. Earnshaw. Chemistry of the Elements, 2nd edition. Oxford: Butterworth-Heinemann, 1997.

Griffith, W. P. "Bicentenary of Four Platinum Group Metals: Part II: Osmium and Iridium—Events Surrounding Their Discoveries." Platinum Metals Review, volume 48, number 4, 2004, pp. 182–189. doi:10.1595/147106704X4844

Gwyn Williams. Electron Binding Energies. http://www.jlab.org/~gwyn/ebindene.html. Accessed on April 30, 2010.

Ho, C. Y., R. W. Powell, and P. E. Liley. "Thermal Conductivity of the Elements: A Comprehensive Review." Journal of Physical and Chemical Reference Data, volume 3, supplement 1, 1974, pp. I–1 to I–796.

Horvath, A. L. "Critical Temperature of Elements and the Periodic System." Journal of Chemical Education, volume 50, number 5, 1973, pp. 335–336. doi:10.1021/ed050p335

Hotop, H., and W. C. Lineberger. "Binding Energies in Atomic Negative Ions: II." Journal of Physical and Chemical Reference Data, volume 14, number 3, 1985, pp. 731–750.

Huheey, James E., Ellen A. Keiter, and Richard L Keiter. Inorganic Chemistry: Principles of Structure and Reactivity, 4th edition. New York: HarperCollins College Publishers, 1993.

Ihde, Aaron J. The Development of Modern Chemistry. New York: Dover Publications, Inc., 1984.

Jr., Elbert J. Little,, and Mark M. Jones. "A Complete Table of Electronegativities." Journal of Chemical Education, volume 37, number 5, 1960, pp. 231–233. doi:10.1021/ed037p231

Kittel, Charles. Introduction to Solid State Physics, 8th edition. Hoboken, NJ: John Wiley & Sons, Inc, 2005.

Lewis, David G. "The Early Life of Smithson Tennant FRS (1761–1815)." Platinum Metals Review, volume 55, number 3, 2011, pp. 196–200. doi:10.1595/147106711X581710

Liboff, Richard L. Introductory Quantum Mechanics, 3rd edition. Reading, MA: Addison Wesley Longman, Inc., 1998.

Lide, David R., editor. CRC Handbook of Chemistry and Physics, 88th edition. Boca Raton, Florida: Taylor & Francis Group, 2008.

Mann, Joseph B., Terry L. Meek, Eugene T. Knight, Joseph F. Capitani, and Leland C. Allen. "Configuration Energies of the d-Block Elements." Journal of the American Chemical Society, volume 122, number 21, 2000, pp. 5132–5137. doi:10.1021/ja9928677

Manuel, O., editor. Origin of Elements in the Solar System: Implications of Post-1957 Observations. New York: Kluwer Academic Publishers, 2000.

Marshall, James L. Discovery of the Elements: A Search for the Fundamental Principles of the Universe, 2nd edition. Boston, MA: Pearson Custom Publishing, 2002.

Martin, W. C. "Electronic Structure of the Elements." The European Physical Journal C — Particles and Fields, volume 15, number 1–4, 2000, pp. 78–79. doi:10.1007/BF02683401

McDonough, W. F. "Compositional Model for the Earth's Core." pp. 547–568 in The Mantle and Core. Edited by Richard W. Carlson. Oxford: Elsevier Ltd., 2005.

Mechtly, Eugene A. "Properties of Materials." pp. 4–1 to 4–33 in Reference Data For Engineers: Radio, Electronics, Computer, and Communications. By Mac E. Van Valkenburg, edited by Wendy M. Middleton. Woburn, MA: Butterworth-Heinemann, 2002. doi:10.1016/B978-075067291-7/50006-6

Miessler, Gary L., and Donald A. Tarr. Inorganic Chemistry, 3rd edition. Upper Saddle River, NJ: Pearson Prentice Hall, 2004.

Nagle, Jeffrey K. "Atomic Polarizability and Electronegativity." Journal of the American Chemical Society, volume 112, number 12, 1990, pp. 4741–4747. doi:10.1021/ja00168a019

Orem, W. H., and R. B. Finkelman. "Coal Formation and Geochemistry." pp. 191–222 in Sediments, Diagenesis, and Sedimentary Rocks. Edited by Fred T. Mackenzie. Oxford: Elsevier Ltd., 2005.

Oxtoby, David W., H. P. Gillis, and Alan Campion. Principles of Modern Chemistry, 6th edition. Belmont, CA: Thomson Brooks/Cole, 2008.

Palme, H., and H. Beer. "Meteorites and the Composition of the Solar Photosphere." pp. 204–206 in Landolt–Börnstein—Group VI: Astronomy and Astrophysics. Edited by H. H. Voigt. New York: Springer–Verlag, 1993. doi:10.1007/10057790_59

Palme, H., and Hugh St. C. O'Neill. "Cosmochemical Estimates of Mantle Composition." pp. 1–38 in The Mantle and Core. Edited by Richard W. Carlson. Oxford: Elsevier Ltd., 2005.

Pauling, Linus. The Nature of the Chemical Bond, 3rd edition. Ithaca, NY: Cornell University Press, 1960.

Pearson, Ralph G. "Absolute Electronegativity and Hardness: Application to Inorganic Chemistry." Inorganic Chemistry, volume 27, number 4, 1988, pp 734–740. doi:10.1021/ic00277a030

Pekka Pyykkö. Self-Consistent, Year-2009 Covalent Radii. http://www.chem.helsinki.fi/~pyykko/Radii09.pdf. Accessed on November 20, 2010.

Prohaska, Thomas, Johanna Irrgeher, Jacqueline Benefield, John K. Böhlke, Lesley A. Chesson, Tyler B. Coplen, Tiping Ding, Philip J. H. Dunn, Manfred Gröning, Norman E. Holden, Harro A. J. Meijer, Heiko Moossen, Antonio Possolo, Yoshio Takahashi, Jochen Vogl, Thomas Walczyk, Jun Wang, Michael E. Wieser, Shigekazu Yoneda, Xiang-Kun Zhu, and Juris Meija. "Standard Atomic Weights of the Elements 2021 (IUPAC Technical Report)." Pure and Applied Chemistry, volume 94, number 5, 2022, pp. 573–600. doi:10.1515/pac-2019-0603

Pyykkö, Pekka, and Michiko Atsumi. "Molecular Double-Bond Covalent Radii for Elements Li-E112." Chemistry - A European Journal, volume 15, number 46, 2009, pp. 12770–12779. doi:10.1002/chem.200901472

Pyykkö, Pekka, and Michiko Atsumi. "Molecular Single-Bond Covalent Radii for Elements 1-118." Chemistry - A European Journal, volume 15, number 1, 2009, pp. 186–197. doi:10.1002/chem.200800987

Pyykkö, Pekka, Sebastian Riedel, and Michael Patzschke. "Triple-Bond Covalent Radii." Chemistry - A European Journal, volume 11, number 12, 2005, pp. 3511–3520. doi:10.1002/chem.200401299

Ringnes, Vivi. "Origin of the Names of Chemical Elements." Journal of Chemical Education, volume 66, number 9, 1989, pp. 731–738. doi:10.1021/ed066p731

Samsonov, G. V., editor. Handbook of the Physicochemical Properties of the Elements. New York: Plenum Publishing Corporation, 1968.

Sansonetti, J. E., and W. C. Martin. "Handbook of Basic Atomic Spectroscopic Data." Journal Of Physical And Chemical Reference Data, volume 34, number 4, 2005, pp. 1559–2259. doi:10.1063/1.1800011

Shannon, R. D. "Revised Effective Ionic Radii and Systematic Studies of Interatomic Distances in Halides and Chalcogenides." Acta Crystallographica Section A, volume 32, number 5, 1976, pp. 751–767. doi:10.1107/S0567739476001551

Silbey, Robert J., Robert A. Alberty, and Moungi G. Bawendi. Physical Chemistry, 4th edition. Hoboken, NJ: John Wiley & Sons, Inc., 2005.

Singman, Charles N. "Atomic Volume and Allotropy of the Elements." Journal of Chemical Education, volume 61, number 2, 1984, pp. 137–142. doi:10.1021/ed061p137

Slater, J. C. "Atomic Radii in Crystals." The Journal of Chemical Physics, volume 41, number 10, 1964, pp. 3199–3204. doi:10.1063/1.1725697

Smith, Derek W. Inorganic Substances: A Prelude to the Study of Descriptive Inorganic Chemistry. Cambridge: Cambridge University Press, 1990.

Stewart, G. R. "Measurement of low-temperature specific heat." Review of Scientific Instruments, volume 54, number 1, 1983, pp. 1–11. doi:10.1063/1.1137207

Stewart, G. R. "Measurement of Low-Temperature Specific Heat." Review of Scientific Instruments, volume 54, number 1, 1983, pp. 1–11. doi:10.1063/1.1137207

Tari, A. The Specific Heat of Matter at Low Temperatures. London: Imperial College Press, 2003.

Vainshtein, Boris K., Vladimir M. Fridkin, and Vladimir L. Indenbom. Structure of Crystals, 2nd edition. Modern Crystallography 2. Edited by Boris K. Vainshtein, A. A. Chernov, and L. A. Shuvalov. Berlin: Springer-Verlag, 1995.

Voigt, H. H., editor. Landolt–Börnstein—Group VI Astronomy and Astrophysics. Berlin: Springer–Verlag, 1993.

Waber, J. T., and Don T. Cromer. "Orbital Radii of Atoms and Ions." Journal of Chemical Physics, volume 42, number 12, 1965, pp. 4116–4123. doi:10.1063/1.1695904

Wagman, Donald D., William H. Evans, Vivian B. Parker, Richard H. Schumm, Iva Halow, Sylvia M. Bailey, Kenneth L. Churney, and Ralph L. Nuttall. "Thermal Conductivity of the Elements: A Comprehensive Review." Journal of Physical and Chemical Reference Data, volume 11, supplement 2, 1982, pp. 2–1 to 2–392.

Waldron, Kimberley A., Erin M. Fehringer, Amy E. Streeb, Jennifer E. Trosky, and Joshua J. Pearson. "Screening Percentages Based on Slater Effective Nuclear Charge as a Versatile Tool for Teaching Periodic Trends." Journal of Chemical Education, volume 78, number 5, 2001, pp. 635–639. doi:10.1021/ed078p635

Weeks, Mary Elvira, and Henry M. Leicester. Discovery of the Elements, 7th edition. Easton, PA: Journal of Chemical Education, 1968.

Yaws, Carl L. "Liquid Density of the Elements." Chemical Engineering, volume 114, number 12, 2007, pp. 44–46.

Yaws, Carl L. The Yaws Handbook of Physical Properties for Hydrocarbons and Chemicals. Houston, TX: Gulf Publishing Company, 2005.

Heaven's Boulevard astronomical sky image for any location, date, and time.
Personalize with a picture and message. Great gift for birthdays, anniversaries, or any special event. Learn more (Link leaves KnowledgeDoor website)
