Rhenium

Rhenium Navigation

Other Elements

By Name

By Symbol

By Number

Quantity

Rhenium Quick Reference

Click button to see citations

Notes

Symbol

Re

Atomic Number

75

Atomic Weight

Rounded

186.21

for regular calculations

Standard

186.207 ± 0.001

for precise calculations

Oxidation States

 7

less common with disagreement

 6

less common

 5

more common with disagreement

 4

more common

 3

more common with disagreement

 2

less common with disagreement

 1

less common

 0

less common

-1

less common

-3

less common

Pauling Electronegativity

1.9

Electron Configuration

Orbital Occupancy

[Xe] 4f14 5d5 6s2

[Xe] represents the closed-shell electron configuration of xenon

Orbital Filling Order

[Xe] 6s2 4f14 5d5

[Xe] represents the closed-shell electron configuration of xenon

Term Symbol

6S5/2

see expanded configuration ...

Ionization Energies

I (1)

7.83352 eV

Electron Affinity

0.15 ± 0.15 eV

1200 ± 1200 cm-1

Density

liquid, 3459.15 K

18.900 g/ml

solid, 25 °C

20.800 g/cm3

Molar Volume

solid, 298 K, 1 atm

8.86 cm3/mol

Melting Point

3458 ± 20 K

Boiling Point

1 atm

5869.15 K

Thermal Conductivity

solid

400 K, polycrystalline

46.1 W/(m K)

300 K, polycrystalline

47.9 W/(m K)

298.2 K, polycrystalline

48.0 W/(m K)

273.2 K, polycrystalline

48.6 W/(m K)

200 K, polycrystalline

51.0 W/(m K)

see all 48 conductivities ...

Pyykkö Covalent Radius

single bond

131 pm

double bond

119 pm

triple bond

110 pm

Atomic Radius

137 pm

Enthalpy of Fusion

1 atm

33.1 kJ/mol

Enthalpy of Vaporization

1 atm

707.1 kJ/mol

Quantity

Rhenium Atomic Structure

Notes

Ionization Energies

I (1)

7.83352 eV

Electron Affinity

0.15 ± 0.15 eV

1200 ± 1200 cm-1

Electron Binding Energies

K    (1s)

71676 eV

LI   (2s)

12527 eV

LII  (2p1/2)

11959 eV

LIII (2p3/2)

10535 eV

see all 19 energies ...

Electron Configuration

Orbital Occupancy

[Xe] 4f14 5d5 6s2

[Xe] represents the closed-shell electron configuration of xenon

Orbital Filling Order

[Xe] 6s2 4f14 5d5

[Xe] represents the closed-shell electron configuration of xenon

Term Symbol

6S5/2

see expanded configuration ...

Clementi-Raimondi Effective Nuclear Charge

1s

Orbital Exponent

73.5478

ζ

Principle Quantum Number

1

n

Effective Nuclear Charge

73.5478

Zeff = ζ × n

2s

Orbital Exponent

27.7049

ζ

Principle Quantum Number

2

n

Effective Nuclear Charge

55.4098

Zeff = ζ × n

see all 14 effective nuclear charges ...

Screening Percentage

87.1%

Fluorescence Yields

ωK

0.955

ωL1

0.15

ωL2

0.304

ωL3

0.271

Coster-Kronig Yields

F12

0.07

F13

0.482

F23

0.131

Quantity

Rhenium Physical Properties

Notes

Density

liquid, 3459.15 K

18.900 g/ml

solid, 25 °C

20.800 g/cm3

Molar Mass

Rounded

186.21 g/mol

for regular calculations

Standard

186.207 ± 0.001 g/mol

for precise calculations

Molar Volume

solid, 298 K, 1 atm

8.86 cm3/mol

Physical Form

silvery-gray metal

Linear Thermal Expansion Coefficient

25 °C

6.2×10-6 K-1

Speed of Sound

solid, 293 K, annealed

4690 m/s to 4710 m/s

calculated value

Young's Modulus

520 GPa

Poisson's Ratio

0.260

Electrical Resistivity

solid, 295 K

18.6×10-8 Ohm m

Photoelectric Work Function

5.0 eV

Thermionic Work Function

5.1 eV

Superconducting Transition Temperature

1.697 ± 0.006 K

Superconducting Critical Magnetic Field at Absolute Zero

198×10-4 T

Mineralogical Hardness

7.0

Vickers Hardness

annealed, 293 K

2450 MN/m2

strained, 293 K

7850 MN/m2

Isothermal Bulk Modulus

300 K

372 GPa

Isothermal Compressibility

300 K

0.00269 GPa-1

Gram Atomic Volume

9 cm3

Quantity

Rhenium Atomic Interaction

Notes

Oxidation States

 7

less common with disagreement

 6

less common

 5

more common with disagreement

 4

more common

 3

more common with disagreement

 2

less common with disagreement

 1

less common

 0

less common

-1

less common

-3

less common

Pauling Electronegativity

1.9

Allred-Rochow Electronegativity

1.46

Configuration Energy

electron volt units

9.46 eV

Pauling units

1.60

Nagle Electronegativity

1.35

Pearson Absolute Electronegativity

4.02 eV

Chemical Hardness

3.87 eV

Cohesive Energy

per mole

775 kJ/mol

per atom

  8.03 eV/atom

Quantity

Rhenium Thermodynamics

Notes

Melting Point

3458 ± 20 K

Boiling Point

1 atm

5869.15 K

Thermal Conductivity

solid

400 K, polycrystalline

46.1 W/(m K)

300 K, polycrystalline

47.9 W/(m K)

298.2 K, polycrystalline

48.0 W/(m K)

273.2 K, polycrystalline

48.6 W/(m K)

200 K, polycrystalline

51.0 W/(m K)

see all 48 conductivities ...

Critical Point

20500 K

Vapor Pressure

5681 °C

100 kPa

4854 °C

10 kPa

4227 °C

1 kPa

3736 °C

100 Pa

3341 °C

10 Pa

3030 °C

1 Pa

Enthalpy of Fusion

1 atm

33.1 kJ/mol

Enthalpy of Vaporization

1 atm

707.1 kJ/mol

Isobaric Molar Heat Capacity

298.15 K, 1 bar

25.48 J/(mol K)

Isobaric Specific Heat Capacity

298.15 K, 1 bar

0.137 J/(g K)

Electronic Heat Capacity Coefficient

2.29 mJ/(mol K2)

Debye Temperature

Low Temperature Limit ( 0 K )

416 K

Room Temperature ( 298 K )

275 K

Quantity

Rhenium Identification

Notes

CAS Number

7440-15-5

Quantity

Rhenium Atomic Size

Notes

Atomic Radius

137 pm

Orbital Radius

131.0 pm

Pyykkö Covalent Radius

single bond

131 pm

double bond

119 pm

triple bond

110 pm

Cordero Covalent Radius

151 pm

Shannon-Prewitt Crystal Radius

ion charge: +4, coordination number: 6

77 pm

ion charge: +5, coordination number: 6

72 pm

ion charge: +6, coordination number: 6

69 pm

ion charge: +7

coordination number: 4

52 pm

coordination number: 6

67 pm

Shannon-Prewitt Effective Ionic Radius

ion charge: +4, coordination number: 6

63 pm

ion charge: +5, coordination number: 6

58 pm

ion charge: +6, coordination number: 6

55 pm

ion charge: +7

coordination number: 4

38 pm

coordination number: 6

53 pm

Batsanov Crystallographic Van Der Waals Radius

205 pm

Batsanov Equilibrium Van Der Waals Radius

235 pm

Slater Atomic-Ionic Radius

135 pm

Quantity

Rhenium Crystal Structure

Notes

Nearest Neighbor Distance

300 K, 1 atm

274 pm

Atomic Concentration

300 K, 1 atm

6.80×1022 cm-3

Quantity

Rhenium History

Notes

Discovery

date of discovery

1925

discoverer

Walter Karl Friedrich Noddack

birth

1893

death

1960

discoverer

Ida Tacke Noddack

birth

1896

death

1978

discoverer

Otto Berg

birth

1874

death

1939

location of discovery

Berlin, Germany

Origin of Element Name

origin

rhenus

origin description

place—Latin name for the Rhine

Origin of Element Symbol

symbol: Re

origin

rhenium

origin description

element name

Formerly Used or Proposed Element Names and Symbols

name

dwi-manganese

no matching symbol specified

Quantity

Rhenium Abundances

Notes

Earth's Crust

7×10-4 ppm

Earth's Mantle

0.32 ppb

primitive mantle

Earth's Core

0.23 ppm

Bulk Earth

0.075 ppm

Ocean Water

1×10-6 ppm

U.S. Coal

<0.001 ppm

estimated from USGS and literature data

Solar System

0.0517

number of atoms for every 106 atoms of silicon

Meteorites

0.28 ± 0.03

base 10 log of the number of atoms for every 1012 atoms of hydrogen

Quantity

Rhenium Nomenclature

Notes

Element Names in Other Languages

French

rhénium

German

Rhenium

Italian

renio

Spanish

renio

Portuguese

rénio

Anions or Anionic Substituent Groups

rhenide

Cations or Cationic Substituent Groups

rhenium

Ligands

rhenido

Heteroatomic Anion

rhenate

'a' Term—Substitutive Nomenclature

rhena

'y' Term—Chains and Rings Nomenclature

rheny

References    (Click the button next to a value above to see complete citation information for that entry)

Anders, Edward, and Nicolas Grevesse. "Abundances of the Elements: Meteoritic and Solar." Geochimica et Cosmochimica Acta, volume 53, number 1, 1989, pp. 197–214. doi:10.1016/0016-7037(89)90286-X

Andersen, T., H. K. Haugen, and H. Hotop. "Binding Energies in Atomic Negative Ions: III." Journal of Physical and Chemical Reference Data, volume 28, number 6, 1999, pp. 1511–1533.

Arblaster, J. W. "What is the True Melting Point of Osmium?" Platinum Metals Review, volume 49, number 4, 2005, pp. 166–168. doi:10.1595/147106705X70264

Arblaster, J. W. "The Thermodynamic Properties of Rhenium on ITS-90." Calphad, volume 20, number 3, 1996, pp. 343–352. doi:10.1016/S0364-5916(96)00036-3

Batsanov, S. S. "Van der Waals Radii of Elements." Inorganic Materials, volume 37, number 9, 2001, pp. 871–885. See abstract

Campbell, J. L. "Fluorescence Yields and Coster–Kronig Probabilities for the Atomic L Subshells. Part II: The L1 Subshell Revisited." Atomic Data and Nuclear Data Tables, volume 95, number 1, 2009, pp. 115–124. doi:10.1016/j.adt.2008.08.002

Campbell, J. L. "Fluorescence Yields and Coster–Kronig Probabilities for the Atomic L Subshells." Atomic Data and Nuclear Data Tables, volume 85, number 2, 2003, pp. 291–315. doi:10.1016/S0092-640X(03)00059-7

Cardarelli, François. Materials Handbook: A Concise Desktop Reference, 2nd edition. London: Springer–Verlag, 2008.

Clementi, E., D. L. Raimondi, and W. P. Reinhardt. "Atomic Screening Constants from SCF Functions. II. Atoms with 37 to 86 Electrons." Journal of Chemical Physics, volume 47, number 4, 1967, pp. 1300–1307. doi:10.1063/1.1712084

Cohen, E. Richard, David R. Lide, and George L. Trigg, editors. AlP Physics Desk Reference, 3rd edition. New York: Springer-Verlag New York, Inc., 2003.

Connelly, Neil G., Ture Damhus, Richard M. Hartshorn, and Alan T. Hutton. Nomenclature of Inorganic Chemistry: IUPAC Recommendations 2005. Cambridge: RSC Publishing, 2005.

Cordero, Beatriz, Verónica Gómez, Ana E. Platero-Prats, Marc Revés, Jorge Echeverría, Eduard Cremades, Flavia Barragán, and Santiago Alvarez. "Covalent Radii Revisited." Dalton Transactions, number 21, 2008, pp 2832–2838. doi:10.1039/b801115j

Cox, P. A. The Elements: Their Origin, Abundance and Distribution. Oxford: Oxford University Press, 1989.

de Podesta, Michael. Understanding the Properties of Matter, 2nd edition. London: Taylor & Francis, 2002.

Dronskowski, Richard. Computational Chemistry of Solid State Materials. Weinheim, Germany: WILEY-VCH Verlag GmbH & Co. KGaA, 2005.

Emsley, John. Nature's Building Blocks: An A-Z Guide to the Elements. Oxford: Oxford University Press, 2003.

Emsley, John. The Elements, 3rd edition. Oxford: Oxford University Press, 1998.

Firestone, Richard B. Table of Isotopes, 8th edition, volume 2. Edited by Virginia S. Shirley, with assistant editors Coral M. Baglin, S. Y. Frank Chu, and Jean Zipkin. New York: John Wiley & Sons, Inc., 1996.

Greenwood, N. N., and A. Earnshaw. Chemistry of the Elements, 2nd edition. Oxford: Butterworth-Heinemann, 1997.

Gwyn Williams. Electron Binding Energies. http://www.jlab.org/~gwyn/ebindene.html. Accessed on April 30, 2010.

Ho, C. Y., R. W. Powell, and P. E. Liley. "Thermal Conductivity of the Elements: A Comprehensive Review." Journal of Physical and Chemical Reference Data, volume 3, supplement 1, 1974, pp. I–1 to I–796.

Horvath, A. L. "Critical Temperature of Elements and the Periodic System." Journal of Chemical Education, volume 50, number 5, 1973, pp. 335–336. doi:10.1021/ed050p335

Huheey, James E., Ellen A. Keiter, and Richard L Keiter. Inorganic Chemistry: Principles of Structure and Reactivity, 4th edition. New York: HarperCollins College Publishers, 1993.

Ihde, Aaron J. The Development of Modern Chemistry. New York: Dover Publications, Inc., 1984.

Jr., Elbert J. Little,, and Mark M. Jones. "A Complete Table of Electronegativities." Journal of Chemical Education, volume 37, number 5, 1960, pp. 231–233. doi:10.1021/ed037p231

Kittel, Charles. Introduction to Solid State Physics, 8th edition. Hoboken, NJ: John Wiley & Sons, Inc, 2005.

Liboff, Richard L. Introductory Quantum Mechanics, 3rd edition. Reading, MA: Addison Wesley Longman, Inc., 1998.

Lide, David R., editor. CRC Handbook of Chemistry and Physics, 88th edition. Boca Raton, Florida: Taylor & Francis Group, 2008.

Mann, Joseph B., Terry L. Meek, Eugene T. Knight, Joseph F. Capitani, and Leland C. Allen. "Configuration Energies of the d-Block Elements." Journal of the American Chemical Society, volume 122, number 21, 2000, pp. 5132–5137. doi:10.1021/ja9928677

Marshall, James L. Discovery of the Elements: A Search for the Fundamental Principles of the Universe, 2nd edition. Boston, MA: Pearson Custom Publishing, 2002.

Martin, W. C. "Electronic Structure of the Elements." The European Physical Journal C — Particles and Fields, volume 15, number 1–4, 2000, pp. 78–79. doi:10.1007/BF02683401

McDonough, W. F. "Compositional Model for the Earth's Core." pp. 547–568 in The Mantle and Core. Edited by Richard W. Carlson. Oxford: Elsevier Ltd., 2005.

Mechtly, Eugene A. "Properties of Materials." pp. 4–1 to 4–33 in Reference Data For Engineers: Radio, Electronics, Computer, and Communications. By Mac E. Van Valkenburg, edited by Wendy M. Middleton. Woburn, MA: Butterworth-Heinemann, 2002. doi:10.1016/B978-075067291-7/50006-6

Miessler, Gary L., and Donald A. Tarr. Inorganic Chemistry, 3rd edition. Upper Saddle River, NJ: Pearson Prentice Hall, 2004.

Nagle, Jeffrey K. "Atomic Polarizability and Electronegativity." Journal of the American Chemical Society, volume 112, number 12, 1990, pp. 4741–4747. doi:10.1021/ja00168a019

Orem, W. H., and R. B. Finkelman. "Coal Formation and Geochemistry." pp. 191–222 in Sediments, Diagenesis, and Sedimentary Rocks. Edited by Fred T. Mackenzie. Oxford: Elsevier Ltd., 2005.

Oxtoby, David W., H. P. Gillis, and Alan Campion. Principles of Modern Chemistry, 6th edition. Belmont, CA: Thomson Brooks/Cole, 2008.

Palme, H., and Hugh St. C. O'Neill. "Cosmochemical Estimates of Mantle Composition." pp. 1–38 in The Mantle and Core. Edited by Richard W. Carlson. Oxford: Elsevier Ltd., 2005.

Pauling, Linus. The Nature of the Chemical Bond, 3rd edition. Ithaca, NY: Cornell University Press, 1960.

Pearson, Ralph G. "Absolute Electronegativity and Hardness: Application to Inorganic Chemistry." Inorganic Chemistry, volume 27, number 4, 1988, pp 734–740. doi:10.1021/ic00277a030

Pekka Pyykkö. Self-Consistent, Year-2009 Covalent Radii. http://www.chem.helsinki.fi/~pyykko/Radii09.pdf. Accessed on November 20, 2010.

Prohaska, Thomas, Johanna Irrgeher, Jacqueline Benefield, John K. Böhlke, Lesley A. Chesson, Tyler B. Coplen, Tiping Ding, Philip J. H. Dunn, Manfred Gröning, Norman E. Holden, Harro A. J. Meijer, Heiko Moossen, Antonio Possolo, Yoshio Takahashi, Jochen Vogl, Thomas Walczyk, Jun Wang, Michael E. Wieser, Shigekazu Yoneda, Xiang-Kun Zhu, and Juris Meija. "Standard Atomic Weights of the Elements 2021 (IUPAC Technical Report)." Pure and Applied Chemistry, volume 94, number 5, 2022, pp. 573–600. doi:10.1515/pac-2019-0603

Pyykkö, Pekka, and Michiko Atsumi. "Molecular Double-Bond Covalent Radii for Elements Li-E112." Chemistry - A European Journal, volume 15, number 46, 2009, pp. 12770–12779. doi:10.1002/chem.200901472

Pyykkö, Pekka, and Michiko Atsumi. "Molecular Single-Bond Covalent Radii for Elements 1-118." Chemistry - A European Journal, volume 15, number 1, 2009, pp. 186–197. doi:10.1002/chem.200800987

Pyykkö, Pekka, Sebastian Riedel, and Michael Patzschke. "Triple-Bond Covalent Radii." Chemistry - A European Journal, volume 11, number 12, 2005, pp. 3511–3520. doi:10.1002/chem.200401299

Quadbeck-Seeger, Hans-Jürgen. World of the Elements: Elements of the World. Translated by José Oliveira. Bad Dürkheim, Germany: Wiley-VCH Verlag GmbH & Co. KGaA, 2007.

Ringnes, Vivi. "Origin of the Names of Chemical Elements." Journal of Chemical Education, volume 66, number 9, 1989, pp. 731–738. doi:10.1021/ed066p731

Roberts, B. W. "Survey of Superconductive Materials and Critical Evaluation of Selected Properties." Journal of Physical and Chemical Reference Data, volume 5, number 3, 1976, pp. 581–821.

Samsonov, G. V., editor. Handbook of the Physicochemical Properties of the Elements. New York: Plenum Publishing Corporation, 1968.

Sansonetti, J. E., and W. C. Martin. "Handbook of Basic Atomic Spectroscopic Data." Journal Of Physical And Chemical Reference Data, volume 34, number 4, 2005, pp. 1559–2259. doi:10.1063/1.1800011

Shannon, R. D. "Revised Effective Ionic Radii and Systematic Studies of Interatomic Distances in Halides and Chalcogenides." Acta Crystallographica Section A, volume 32, number 5, 1976, pp. 751–767. doi:10.1107/S0567739476001551

Silbey, Robert J., Robert A. Alberty, and Moungi G. Bawendi. Physical Chemistry, 4th edition. Hoboken, NJ: John Wiley & Sons, Inc., 2005.

Singman, Charles N. "Atomic Volume and Allotropy of the Elements." Journal of Chemical Education, volume 61, number 2, 1984, pp. 137–142. doi:10.1021/ed061p137

Slater, J. C. "Atomic Radii in Crystals." The Journal of Chemical Physics, volume 41, number 10, 1964, pp. 3199–3204. doi:10.1063/1.1725697

Smith, Derek W. Inorganic Substances: A Prelude to the Study of Descriptive Inorganic Chemistry. Cambridge: Cambridge University Press, 1990.

Stewart, G. R. "Measurement of low-temperature specific heat." Review of Scientific Instruments, volume 54, number 1, 1983, pp. 1–11. doi:10.1063/1.1137207

Stewart, G. R. "Measurement of Low-Temperature Specific Heat." Review of Scientific Instruments, volume 54, number 1, 1983, pp. 1–11. doi:10.1063/1.1137207

Tari, A. The Specific Heat of Matter at Low Temperatures. London: Imperial College Press, 2003.

Vainshtein, Boris K., Vladimir M. Fridkin, and Vladimir L. Indenbom. Structure of Crystals, 2nd edition. Modern Crystallography 2. Edited by Boris K. Vainshtein, A. A. Chernov, and L. A. Shuvalov. Berlin: Springer-Verlag, 1995.

Voigt, H. H., editor. Landolt–Börnstein—Group VI Astronomy and Astrophysics. Berlin: Springer–Verlag, 1993.

Waber, J. T., and Don T. Cromer. "Orbital Radii of Atoms and Ions." Journal of Chemical Physics, volume 42, number 12, 1965, pp. 4116–4123. doi:10.1063/1.1695904

Wagman, Donald D., William H. Evans, Vivian B. Parker, Richard H. Schumm, Iva Halow, Sylvia M. Bailey, Kenneth L. Churney, and Ralph L. Nuttall. "Thermal Conductivity of the Elements: A Comprehensive Review." Journal of Physical and Chemical Reference Data, volume 11, supplement 2, 1982, pp. 2–1 to 2–392.

Wagner, H. J. "Some Footnotes on the History of Masurium." Journal of Chemical Education, volume 82, number 9, 2005, p. 1309. doi:10.1021/ed082p1309

Waldron, Kimberley A., Erin M. Fehringer, Amy E. Streeb, Jennifer E. Trosky, and Joshua J. Pearson. "Screening Percentages Based on Slater Effective Nuclear Charge as a Versatile Tool for Teaching Periodic Trends." Journal of Chemical Education, volume 78, number 5, 2001, pp. 635–639. doi:10.1021/ed078p635

Weeks, Mary Elvira, and Henry M. Leicester. Discovery of the Elements, 7th edition. Easton, PA: Journal of Chemical Education, 1968.

Yaws, Carl L. "Liquid Density of the Elements." Chemical Engineering, volume 114, number 12, 2007, pp. 44–46.

Yaws, Carl L. The Yaws Handbook of Physical Properties for Hydrocarbons and Chemicals. Houston, TX: Gulf Publishing Company, 2005.

Heaven's Boulevard astronomical
sky image for any location, date, and time. Personalize with a picture and message. Great gift for birthdays, anniversaries, or any special event. Learn more (Link leaves KnowledgeDoor website)
