Rhodium

Rhodium Navigation

Other Elements

By Name

By Symbol

By Number

Quantity

Rhodium Quick Reference

Click button to see citations

Notes

Symbol

Rh

Atomic Number

45

Atomic Weight

Rounded

102.91

for regular calculations

Standard

102.90549 ± 0.00002

for precise calculations

Oxidation States

 6

less common

 5

less common

 4

less common with disagreement

 3

more common

 2

less common with disagreement

 1

less common

 0

less common

-1

less common

Pauling Electronegativity

2.28

Electron Configuration

Orbital Occupancy

[Kr] 4d8 5s1

[Kr] represents the closed-shell electron configuration of krypton

Orbital Filling Order

[Kr] 5s1 4d8

[Kr] represents the closed-shell electron configuration of krypton

Term Symbol

4F9/2

see expanded configuration ...

Ionization Energies

I   (1)

 7.45890 eV

II  (2)

18.08 eV

III (3)

31.06 eV

Electron Affinity

1.14289 ± 0.00020 eV

 9218.0 ± 1.5 cm-1

Density

liquid, 2237.15 K

10.650 g/ml

solid, 25 °C

12.400 g/cm3

Molar Volume

solid, 298 K, 1 atm

8.28 cm3/mol

Melting Point

1 atm

2236 K

ITS-90 first-quality, secondary reference point (freezing point)

Boiling Point

1 atm

4114 ± 90 K

reference stated that the uncertainty may be larger than indicated

Thermal Conductivity

solid

400 K

146 W/(m K)

300 K

150 W/(m K)

298.2 K

150 W/(m K)

273.2 K

151 W/(m K)

200 K

154 W/(m K)

see all 46 conductivities ...

Pyykkö Covalent Radius

single bond

125 pm

double bond

110 pm

triple bond

106 pm

Atomic Radius

134 pm

Enthalpy of Fusion

1 atm

21.55 kJ/mol

Enthalpy of Vaporization

1 atm

495.4 kJ/mol

Quantity

Rhodium Atomic Structure

Notes

Ionization Energies

I   (1)

 7.45890 eV

II  (2)

18.08 eV

III (3)

31.06 eV

Electron Affinity

1.14289 ± 0.00020 eV

 9218.0 ± 1.5 cm-1

Electron Binding Energies

K    (1s)

23220 eV

LI   (2s)

 3412 eV

LII  (2p1/2)

 3146 eV

LIII (2p3/2)

 3004 eV

see all 12 energies ...

Electron Configuration

Orbital Occupancy

[Kr] 4d8 5s1

[Kr] represents the closed-shell electron configuration of krypton

Orbital Filling Order

[Kr] 5s1 4d8

[Kr] represents the closed-shell electron configuration of krypton

Term Symbol

4F9/2

see expanded configuration ...

Clementi-Raimondi Effective Nuclear Charge

1s

Orbital Exponent

44.0756

ζ

Principle Quantum Number

1

n

Effective Nuclear Charge

44.0756

Zeff = ζ × n

2s

Orbital Exponent

16.5773

ζ

Principle Quantum Number

2

n

Effective Nuclear Charge

33.1546

Zeff = ζ × n

see all 10 effective nuclear charges ...

Screening Percentage

86.2%

Fluorescence Yields

ωK

0.807

ωL1

0.013

ωL2

0.043

ωL3

0.046

Coster-Kronig Yields

F12

0.10

F13

0.57

F23

0.13

Quantity

Rhodium Physical Properties

Notes

Density

liquid, 2237.15 K

10.650 g/ml

solid, 25 °C

12.400 g/cm3

Molar Mass

Rounded

102.91 g/mol

for regular calculations

Standard

102.90549 ± 0.00002 g/mol

for precise calculations

Molar Volume

solid, 298 K, 1 atm

8.28 cm3/mol

Physical Form

silvery-white metal

Linear Thermal Expansion Coefficient

25 °C

8.2×10-6 K-1

283 K

8.45×10-6 K-1

85 K

4.18×10-6 K-1

75 K

3.50×10-6 K-1

65 K

2.77×10-6 K-1

57.5 K

2.23×10-6 K-1

see all 20 coefficients ...

Specific Gravity

68 °F, water at 4 °C (39.2 °F)

12.41

Young's Modulus

379 GPa

Poisson's Ratio

0.260

Electrical Resistivity

solid, 295 K

4.8×10-8 Ohm m

Contact Potential

4.52 eV

Photoelectric Work Function

4.57 eV

Thermionic Work Function

4.80 eV

Superconducting Transition Temperature

0.000325 K

Superconducting Critical Magnetic Field at Absolute Zero

0.049×10-4 T

Mineralogical Hardness

6.0

Vickers Hardness

annealed at 1873 K for 1.5 hr, purity - 99.6%

293 K

1246 MN/m2

723 K

 942 MN/m2

1348 K

 461 MN/m2

Reflectivity

surface polished

0.5 μm

76%

0.6 μm

77%

0.8 μm

81%

see all 8 reflectivities ...

Isothermal Bulk Modulus

300 K

270.4 GPa

Isothermal Compressibility

300 K

0.00369 GPa-1

Gram Atomic Volume

8 cm3

Quantity

Rhodium Atomic Interaction

Notes

Oxidation States

 6

less common

 5

less common

 4

less common with disagreement

 3

more common

 2

less common with disagreement

 1

less common

 0

less common

-1

less common

Pauling Electronegativity

2.28

Allred-Rochow Electronegativity

1.45

Configuration Energy

electron volt units

9.259 eV

Pauling units

1.56

Allred Electronegativity

oxidation state: 2

2.28

Ghosh-Gupta Electronegativity

3.4611 eV

Nagle Electronegativity

1.39

Pearson Absolute Electronegativity

4.30 eV

Chemical Hardness

3.16 eV

Cohesive Energy

per mole

554 kJ/mol

per atom

  5.75 eV/atom

Quantity

Rhodium Thermodynamics

Notes

Melting Point

1 atm

2236 K

ITS-90 first-quality, secondary reference point (freezing point)

Boiling Point

1 atm

4114 ± 90 K

reference stated that the uncertainty may be larger than indicated

Thermal Conductivity

solid

400 K

146 W/(m K)

300 K

150 W/(m K)

298.2 K

150 W/(m K)

273.2 K

151 W/(m K)

200 K

154 W/(m K)

see all 46 conductivities ...

Critical Point

7000 K

Vapor Pressure

4114 K

1 atm

4110 K

1 bar

3530 K

1×10-1 bar

3102 K

1×10-2 bar

2236 K

5.050×10-6 bar

melting point

see all 19 pressures ...

Enthalpy of Fusion

1 atm

21.55 kJ/mol

Enthalpy of Vaporization

1 atm

495.4 kJ/mol

Isobaric Molar Heat Capacity

298.15 K, 1 bar

24.98 J/(mol K)

Isobaric Specific Heat Capacity

298.15 K, 1 bar

0.243 J/(g K)

Electronic Heat Capacity Coefficient

4.65 mJ/(mol K2)

Debye Temperature

Low Temperature Limit ( 0 K )

512 K

Room Temperature ( 298 K )

350 K

Quantity

Rhodium Identification

Notes

CAS Number

7440-16-6

ICSC Number

powder

1247

RTECS Number

VI9069000

Quantity

Rhodium Atomic Size

Notes

Atomic Radius

134 pm

Orbital Radius

136.4 pm

Pyykkö Covalent Radius

single bond

125 pm

double bond

110 pm

triple bond

106 pm

Cordero Covalent Radius

142 pm

Shannon-Prewitt Crystal Radius

ion charge: +3, coordination number: 6

80.5 pm

ion charge: +4, coordination number: 6

74 pm

ion charge: +5, coordination number: 6

69 pm

Shannon-Prewitt Effective Ionic Radius

ion charge: +3, coordination number: 6

66.5 pm

ion charge: +4, coordination number: 6

60 pm

ion charge: +5, coordination number: 6

55 pm

Batsanov Crystallographic Van Der Waals Radius

2.0×102 pm

Batsanov Equilibrium Van Der Waals Radius

232 pm

Slater Atomic-Ionic Radius

135 pm

Quantity

Rhodium Crystal Structure

Notes

Nearest Neighbor Distance

300 K, 1 atm

269 pm

Atomic Concentration

300 K, 1 atm

7.26×1022 cm-3

Quantity

Rhodium History

Notes

Discovery

date of discovery

1803

discoverer

William Hyde Wollaston

birth

August 6, 1766

death

December 22, 1828

location of discovery

London, England

Origin of Element Name

origin

rhodon

origin description

color—Greek for rose or rose colored

Origin of Element Symbol

symbol: Rh

origin

rhodium

origin description

element name

Formerly Used or Proposed Element Names and Symbols

symbol

R

Quantity

Rhodium Abundances

Notes

Earth's Crust

1×10-3 ppm

Earth's Mantle

0.93 ppb

primitive mantle

Earth's Core

0.74 ppm

Bulk Earth

0.24 ppm

U.S. Coal

<0.001 ppm

estimated from USGS and literature data

Solar System

0.344

number of atoms for every 106 atoms of silicon

Sun

1.12 ± 0.12

base 10 log of the number of atoms for every 1012 atoms of hydrogen

Meteorites

1.08 ± 0.08

base 10 log of the number of atoms for every 1012 atoms of hydrogen

Quantity

Rhodium Nomenclature

Notes

Element Names in Other Languages

French

rhodium

German

Rhodium

Italian

rodio

Spanish

rodio

Portuguese

ródio

Anions or Anionic Substituent Groups

rhodide

Cations or Cationic Substituent Groups

rhodium

Ligands

rhodido

Heteroatomic Anion

rhodate

'a' Term—Substitutive Nomenclature

rhoda

'y' Term—Chains and Rings Nomenclature

rhody

References    (Click the button next to a value above to see complete citation information for that entry)

Allred, A. L. "Electronegativity Values from Thermochemical Data." Journal of Inorganic and Nuclear Chemistry, volume 17, number 3-4, 1961, pp. 215–221. doi:10.1016/0022-1902(61)80142-5

Anders, Edward, and Nicolas Grevesse. "Abundances of the Elements: Meteoritic and Solar." Geochimica et Cosmochimica Acta, volume 53, number 1, 1989, pp. 197–214. doi:10.1016/0016-7037(89)90286-X

Andersen, T., H. K. Haugen, and H. Hotop. "Binding Energies in Atomic Negative Ions: III." Journal of Physical and Chemical Reference Data, volume 28, number 6, 1999, pp. 1511–1533.

Arblaster, J. W. "Vapour Pressure Equations for the Platinum Group Elements." Platinum Metals Review, volume 51, number 3, 2007, pp. 130–135. doi:10.1595/147106707X213830

Arblaster, J. W. "Thermodynamic Properties of the Platinum Metals on ITS-90." Platinum Metals Review, volume 40, number 2, 1996, pp. 62–63.

Barsan, Michael E., editor. NIOSH Pocket Guide to Chemical Hazards. Cincinnati, Ohio: NIOSH Publications, 2007.

Batsanov, S. S. "Van der Waals Radii of Elements." Inorganic Materials, volume 37, number 9, 2001, pp. 871–885. See abstract

Bedford, R. E., G. Bonnier, H. Maas, and F. Pavese. "Recommended Values of Temperature on the International Temperature Scale of 1990 for a Selected Set of Secondary Reference Points." Metrologia, volume 33, number 2, 1996, pp. 133–154. doi:10.1088/0026-1394/33/2/3

Buchal, Ch., F. Pobell, R. M. Mueller, M. Kubota, and J. R. Owers-Bradley. "Superconductivity of Rhodium at Ultralow Temperatures." Physical Review Letters, volume 50, number 1, 1983, pp. 64–67. doi:10.1103/PhysRevLett.50.64

Campbell, J. L. "Fluorescence Yields and Coster–Kronig Probabilities for the Atomic L Subshells." Atomic Data and Nuclear Data Tables, volume 85, number 2, 2003, pp. 291–315. doi:10.1016/S0092-640X(03)00059-7

Cardarelli, François. Materials Handbook: A Concise Desktop Reference, 2nd edition. London: Springer–Verlag, 2008.

Clementi, E., D. L. Raimondi, and W. P. Reinhardt. "Atomic Screening Constants from SCF Functions. II. Atoms with 37 to 86 Electrons." Journal of Chemical Physics, volume 47, number 4, 1967, pp. 1300–1307. doi:10.1063/1.1712084

Cohen, E. Richard, David R. Lide, and George L. Trigg, editors. AlP Physics Desk Reference, 3rd edition. New York: Springer-Verlag New York, Inc., 2003.

Connelly, Neil G., Ture Damhus, Richard M. Hartshorn, and Alan T. Hutton. Nomenclature of Inorganic Chemistry: IUPAC Recommendations 2005. Cambridge: RSC Publishing, 2005.

Cordero, Beatriz, Verónica Gómez, Ana E. Platero-Prats, Marc Revés, Jorge Echeverría, Eduard Cremades, Flavia Barragán, and Santiago Alvarez. "Covalent Radii Revisited." Dalton Transactions, number 21, 2008, pp 2832–2838. doi:10.1039/b801115j

Cox, P. A. The Elements: Their Origin, Abundance and Distribution. Oxford: Oxford University Press, 1989.

de Podesta, Michael. Understanding the Properties of Matter, 2nd edition. London: Taylor & Francis, 2002.

Dronskowski, Richard. Computational Chemistry of Solid State Materials. Weinheim, Germany: WILEY-VCH Verlag GmbH & Co. KGaA, 2005.

Emsley, John. Nature's Building Blocks: An A-Z Guide to the Elements. Oxford: Oxford University Press, 2003.

Emsley, John. The Elements, 3rd edition. Oxford: Oxford University Press, 1998.

Firestone, Richard B. Table of Isotopes, 8th edition, volume 2. Edited by Virginia S. Shirley, with assistant editors Coral M. Baglin, S. Y. Frank Chu, and Jean Zipkin. New York: John Wiley & Sons, Inc., 1996.

Ghosh, Dulal C., and Kartick Gupta. "A New Scale Of Electronegativity Of 54 Elements Of Periodic Table Based On Polarizability Of Atoms." Journal of Theoretical and Computational Chemistry, volume 5, number 4, 2006, pp. 895–911. doi:10.1142/S0219633606002726

Greenwood, N. N., and A. Earnshaw. Chemistry of the Elements, 2nd edition. Oxford: Butterworth-Heinemann, 1997.

Griffith, W. P. "Bicentenary of Four Platinum Group Metals: Part I: Rhodium and Palladium—Events Surrounding Their Discoveries." Platinum Metals Review, volume 47, number 4, 2003, pp. 175–183.

Gwyn Williams. Electron Binding Energies. http://www.jlab.org/~gwyn/ebindene.html. Accessed on April 30, 2010.

Ho, C. Y., R. W. Powell, and P. E. Liley. "Thermal Conductivity of the Elements: A Comprehensive Review." Journal of Physical and Chemical Reference Data, volume 3, supplement 1, 1974, pp. I–1 to I–796.

Höhne, G. W. H., W. F. Hemminger, and H.-J. Flammersheim. Differential Scanning Calorimetry, 2nd edition. Berlin: Springer–Verlag, 2003.

Horvath, A. L. "Critical Temperature of Elements and the Periodic System." Journal of Chemical Education, volume 50, number 5, 1973, pp. 335–336. doi:10.1021/ed050p335

Hotop, H., and W. C. Lineberger. "Binding Energies in Atomic Negative Ions: II." Journal of Physical and Chemical Reference Data, volume 14, number 3, 1985, pp. 731–750.

Huheey, James E., Ellen A. Keiter, and Richard L Keiter. Inorganic Chemistry: Principles of Structure and Reactivity, 4th edition. New York: HarperCollins College Publishers, 1993.

Ihde, Aaron J. The Development of Modern Chemistry. New York: Dover Publications, Inc., 1984.

International Labour Organization (ILO). International Chemical Safety Card for Rhodium (Powder). http://www.ilo.org/legacy/english/protection/safework/cis/products/icsc/dtasht/_icsc12/icsc1247.htm. Accessed on May 4, 2010.

Jr., Elbert J. Little,, and Mark M. Jones. "A Complete Table of Electronegativities." Journal of Chemical Education, volume 37, number 5, 1960, pp. 231–233. doi:10.1021/ed037p231

Kaxiras, Efthimios. Atomic and Electronic Structure of Solids. Cambridge: Cambridge University Press, 2003.

Kittel, Charles. Introduction to Solid State Physics, 8th edition. Hoboken, NJ: John Wiley & Sons, Inc, 2005.

Krause, M. O. "Atomic Radiative and Radiationless Yields for K and L Shells." Journal of Physical and Chemical Reference Data, volume 8, number 2, 1979, pp. 307–327.

Liboff, Richard L. Introductory Quantum Mechanics, 3rd edition. Reading, MA: Addison Wesley Longman, Inc., 1998.

Lide, David R., editor. CRC Handbook of Chemistry and Physics, 88th edition. Boca Raton, Florida: Taylor & Francis Group, 2008.

Mann, Joseph B., Terry L. Meek, Eugene T. Knight, Joseph F. Capitani, and Leland C. Allen. "Configuration Energies of the d-Block Elements." Journal of the American Chemical Society, volume 122, number 21, 2000, pp. 5132–5137. doi:10.1021/ja9928677

Manuel, O., editor. Origin of Elements in the Solar System: Implications of Post-1957 Observations. New York: Kluwer Academic Publishers, 2000.

Marshall, James L. Discovery of the Elements: A Search for the Fundamental Principles of the Universe, 2nd edition. Boston, MA: Pearson Custom Publishing, 2002.

Martin, W. C. "Electronic Structure of the Elements." The European Physical Journal C — Particles and Fields, volume 15, number 1–4, 2000, pp. 78–79. doi:10.1007/BF02683401

McDonough, W. F. "Compositional Model for the Earth's Core." pp. 547–568 in The Mantle and Core. Edited by Richard W. Carlson. Oxford: Elsevier Ltd., 2005.

Mechtly, Eugene A. "Properties of Materials." pp. 4–1 to 4–33 in Reference Data For Engineers: Radio, Electronics, Computer, and Communications. By Mac E. Van Valkenburg, edited by Wendy M. Middleton. Woburn, MA: Butterworth-Heinemann, 2002. doi:10.1016/B978-075067291-7/50006-6

Miessler, Gary L., and Donald A. Tarr. Inorganic Chemistry, 3rd edition. Upper Saddle River, NJ: Pearson Prentice Hall, 2004.

Moore, Charlotte E. Ionization Potentials and Ionization Limits Derived from the Analyses of Optical Spectra. Washington, D.C.: National Bureau of Standards, 1970.

Nagle, Jeffrey K. "Atomic Polarizability and Electronegativity." Journal of the American Chemical Society, volume 112, number 12, 1990, pp. 4741–4747. doi:10.1021/ja00168a019

National Institute for Occupational Safety and Health (NIOSH). International Chemical Safety Card for Rhodium (Powder). http://www.cdc.gov/niosh/ipcsneng/neng1247.html. Accessed on May 4, 2010.

National Institute for Occupational Safety and Health (NIOSH). The Registry of Toxic Effects of Chemical Substances for Rhodium. http://www.cdc.gov/niosh-rtecs/vi8a61c8.html. Accessed on May 5, 2010.

Nicholas, J. V., and D. R. White. "Temperature." pp. 8–41 in Measurement of the Thermodynamic Properties of Single Phases. Edited by A. R. H. Goodwin, W. A. Wakeham, and K. N. Marsh. Amsterdam: Elsevier Science, 2003.

Orem, W. H., and R. B. Finkelman. "Coal Formation and Geochemistry." pp. 191–222 in Sediments, Diagenesis, and Sedimentary Rocks. Edited by Fred T. Mackenzie. Oxford: Elsevier Ltd., 2005.

Oxtoby, David W., H. P. Gillis, and Alan Campion. Principles of Modern Chemistry, 6th edition. Belmont, CA: Thomson Brooks/Cole, 2008.

Palme, H., and H. Beer. "Meteorites and the Composition of the Solar Photosphere." pp. 204–206 in Landolt–Börnstein—Group VI: Astronomy and Astrophysics. Edited by H. H. Voigt. New York: Springer–Verlag, 1993. doi:10.1007/10057790_59

Palme, H., and Hugh St. C. O'Neill. "Cosmochemical Estimates of Mantle Composition." pp. 1–38 in The Mantle and Core. Edited by Richard W. Carlson. Oxford: Elsevier Ltd., 2005.

Pearson, Ralph G. "Absolute Electronegativity and Hardness: Application to Inorganic Chemistry." Inorganic Chemistry, volume 27, number 4, 1988, pp 734–740. doi:10.1021/ic00277a030

Pekka Pyykkö. Self-Consistent, Year-2009 Covalent Radii. http://www.chem.helsinki.fi/~pyykko/Radii09.pdf. Accessed on November 20, 2010.

Prohaska, Thomas, Johanna Irrgeher, Jacqueline Benefield, John K. Böhlke, Lesley A. Chesson, Tyler B. Coplen, Tiping Ding, Philip J. H. Dunn, Manfred Gröning, Norman E. Holden, Harro A. J. Meijer, Heiko Moossen, Antonio Possolo, Yoshio Takahashi, Jochen Vogl, Thomas Walczyk, Jun Wang, Michael E. Wieser, Shigekazu Yoneda, Xiang-Kun Zhu, and Juris Meija. "Standard Atomic Weights of the Elements 2021 (IUPAC Technical Report)." Pure and Applied Chemistry, volume 94, number 5, 2022, pp. 573–600. doi:10.1515/pac-2019-0603

Pyykkö, Pekka, and Michiko Atsumi. "Molecular Double-Bond Covalent Radii for Elements Li-E112." Chemistry - A European Journal, volume 15, number 46, 2009, pp. 12770–12779. doi:10.1002/chem.200901472

Pyykkö, Pekka, and Michiko Atsumi. "Molecular Single-Bond Covalent Radii for Elements 1-118." Chemistry - A European Journal, volume 15, number 1, 2009, pp. 186–197. doi:10.1002/chem.200800987

Pyykkö, Pekka, Sebastian Riedel, and Michael Patzschke. "Triple-Bond Covalent Radii." Chemistry - A European Journal, volume 11, number 12, 2005, pp. 3511–3520. doi:10.1002/chem.200401299

Ringnes, Vivi. "Origin of the Names of Chemical Elements." Journal of Chemical Education, volume 66, number 9, 1989, pp. 731–738. doi:10.1021/ed066p731

Samsonov, G. V., editor. Handbook of the Physicochemical Properties of the Elements. New York: Plenum Publishing Corporation, 1968.

Sansonetti, J. E., and W. C. Martin. "Handbook of Basic Atomic Spectroscopic Data." Journal Of Physical And Chemical Reference Data, volume 34, number 4, 2005, pp. 1559–2259. doi:10.1063/1.1800011

Shannon, R. D. "Revised Effective Ionic Radii and Systematic Studies of Interatomic Distances in Halides and Chalcogenides." Acta Crystallographica Section A, volume 32, number 5, 1976, pp. 751–767. doi:10.1107/S0567739476001551

Silbey, Robert J., Robert A. Alberty, and Moungi G. Bawendi. Physical Chemistry, 4th edition. Hoboken, NJ: John Wiley & Sons, Inc., 2005.

Singman, Charles N. "Atomic Volume and Allotropy of the Elements." Journal of Chemical Education, volume 61, number 2, 1984, pp. 137–142. doi:10.1021/ed061p137

Slater, J. C. "Atomic Radii in Crystals." The Journal of Chemical Physics, volume 41, number 10, 1964, pp. 3199–3204. doi:10.1063/1.1725697

Smith, Derek W. Inorganic Substances: A Prelude to the Study of Descriptive Inorganic Chemistry. Cambridge: Cambridge University Press, 1990.

Stewart, G. R. "Measurement of low-temperature specific heat." Review of Scientific Instruments, volume 54, number 1, 1983, pp. 1–11. doi:10.1063/1.1137207

Stewart, G. R. "Measurement of Low-Temperature Specific Heat." Review of Scientific Instruments, volume 54, number 1, 1983, pp. 1–11. doi:10.1063/1.1137207

Tari, A. The Specific Heat of Matter at Low Temperatures. London: Imperial College Press, 2003.

Vainshtein, Boris K., Vladimir M. Fridkin, and Vladimir L. Indenbom. Structure of Crystals, 2nd edition. Modern Crystallography 2. Edited by Boris K. Vainshtein, A. A. Chernov, and L. A. Shuvalov. Berlin: Springer-Verlag, 1995.

Voigt, H. H., editor. Landolt–Börnstein—Group VI Astronomy and Astrophysics. Berlin: Springer–Verlag, 1993.

Waber, J. T., and Don T. Cromer. "Orbital Radii of Atoms and Ions." Journal of Chemical Physics, volume 42, number 12, 1965, pp. 4116–4123. doi:10.1063/1.1695904

Wagman, Donald D., William H. Evans, Vivian B. Parker, Richard H. Schumm, Iva Halow, Sylvia M. Bailey, Kenneth L. Churney, and Ralph L. Nuttall. "Thermal Conductivity of the Elements: A Comprehensive Review." Journal of Physical and Chemical Reference Data, volume 11, supplement 2, 1982, pp. 2–1 to 2–392.

Waldron, Kimberley A., Erin M. Fehringer, Amy E. Streeb, Jennifer E. Trosky, and Joshua J. Pearson. "Screening Percentages Based on Slater Effective Nuclear Charge as a Versatile Tool for Teaching Periodic Trends." Journal of Chemical Education, volume 78, number 5, 2001, pp. 635–639. doi:10.1021/ed078p635

Weeks, Mary Elvira, and Henry M. Leicester. Discovery of the Elements, 7th edition. Easton, PA: Journal of Chemical Education, 1968.

White, G. K., and A. T. Pawlowicz. "Thermal Expansion of Rhodium, Iridium, and Palladium at Low Temperatures." Journal of Low Temperature Physics, volume 2, number 5-6, 1970, pp. 631–639. doi:10.1007/BF00628279

Yaws, Carl L. "Liquid Density of the Elements." Chemical Engineering, volume 114, number 12, 2007, pp. 44–46.

Yaws, Carl L. The Yaws Handbook of Physical Properties for Hydrocarbons and Chemicals. Houston, TX: Gulf Publishing Company, 2005.

Heaven's Boulevard astronomical sky image for any location, date, and time. Personalize with a picture and message. Great gift for birthdays, anniversaries, or any special event. Learn more (Link leaves KnowledgeDoor website)
